Key Characteristics |
Product Number |
178922 |
| Trade Name |
i4311 |
| Brand Name |
Brady® |
| Warranty |
5 Years |
| Dimensions (mm) |
Height |
241.3 |
| Width |
228.6 |
| Depth |
330.2 |
| Weight (kg) |
5.85 |
Product Features
|
Application |
Asset Tracking, Circuit Board Labelling, Data and telecommunications Labelling, Electrical Labelling, Exit and Egress Marking, Facility Identification, Food and Beverage Process Labelling, Floor Marking, General identification, Hazard Communication Identification, Inspection Tagging, Lockout Tagout, Pipe and Valve Marking, Safety Identification, Security Identification, Solar Panel Labelling, Temperature Indicating Labelling, Warehouse Marking, Wire and cable Labelling, Lean and 5S Labelling, Inventory and Inspection Labelling, Laboratory Labelling, Cold temperature Labelling, GHS & Chemical Labels, Tamper Indicating, Equipment, Machinery, Component and Equipment Labelling, Maintenance, Temporary Labelling |
| Built-In Label Wizards |
No |
| Connectivity Options |
USB, Wi-Fi, Bluetooth, Cabled, Ethernet, USB-C |
| Cutter Type |
Auto Cutter |
| Display Type |
Colour LCD Touch Screen |
| Keyboard Type |
None |
| Memory |
1GB RAM, 8GB Flash |
| Device Connectivity |
Mobile device connected, PC connected, Stand-alone |
| User Interface Type |
Mobile device, PC, Touch Screen |
| Auto Shut-Off / Power Conserve |
Yes |
Printing Specifications
|
Automatic Label Set Up |
Yes |
| Barcode Symbologies – 2D |
Aztec, Data Matrix, MicroPDF417, PDF417, QR code |
| Barcode Symbologies – Linear |
Codabar, Code 128A, Code 128B, Code 128C, Code 39, Code 93, EAN-13, EAN-8, HIBC, Interleaved 2 of 5, JAN-8, MSI, Plessey, UPC-A |
| Calibration Required? |
No |
| Colour Printing Capability |
Single Colour |
| Font Sizes |
4 – 250 pt |
| Font Styles |
85 font options through Brady Workstation Express Labels, Arial, Times New Roman |
| Maximum Labels per Day |
5000 |
| Maximum Print Speed (mm/sec) |
101.6 |
| Print resolution (dpi) |
300 |
| Print Technology |
Thermal Transfer |
| On Screen Indicators |
Bluetooth Status, Data Reception, Digital Clock, Error Messaging, Ribbon and label part number recognition, Ribbon Remaining, Supply Remaining, USB Connection, WiFi |
| Compatibility |
Compatible Media |
B30-, B30C-, B30EP-, B33-, B33C-, B33D-, B33FP-, B33FT-, B33R- |
| Label Material Types |
FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Magnetic Polyester, Metal-detectable Polyester, Metallic, Non-metal Polyester, Metallized Polyester, Metallized Polyester with Polyester Overlaminate, Nylon Cloth, Paper, Phosphorescent Polyester, Polyester, Polyester with Polyester Overlaminate, Polyimide, Polyolefin, Polypropylene, Polyvinylfluoride, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallized Polyester, Vinyl, Vinyl Cloth |
| Materials Supported |
Continuous, Custom, Die-cut |
| Custom Labels Available |
Yes |
| Maximum Label/Tape Width (mm) |
107.95 |
| Maximum Print Width (mm) |
107.95 |
| Software Compatibility |
Brady LINK360®, Brady Workstation, Express Labels Mobile App, Software development kit, Windows based driver for 3rd party software use |
| Languages Available |
Bulgarian, Chinese (Simplified), Chinese (Traditional), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (Canada), French (France), German, Hungarian, Italian, Korean, Norwegian, Polish, Portuguese (Brazil), Portuguese (Portugal), Romanian, Russian, Spanish (Mexico), Spanish (Spain), Swedish, Thai, Turkish |
