| Key Characteristics |
Product Number |
7031633 |
| Trade Name |
i7500 |
| Brand Name |
Brady® |
| Warranty |
5 Years |
| Dimensions (mm) |
Height |
370.84 |
| Width |
292.10 |
| Depth |
530.86 |
| Weight (kg) |
18.14 |
Product Features
|
Application |
Asset Tracking, Barcode Labeling, Circuit Board Labeling, Data and Telecommunications Labeling, Electrical Labeling, General Identification, Inventory and Inspection Labeling, Laboratory Labeling, Solar Panel Labeling, Tamper Indicating Labels, Warehouse Marking, Wire and Cable Labeling |
| Connectivity Options |
Bluetooth, Ethernet, USB, Wi-Fi |
| Cutter Type |
None |
| Display Type |
Color LCD Touch Screen |
| Keyboard Type |
None |
| Memory |
512 MB RAM, 195 MB IFFS Flash |
| Device Connectivity |
Mobile device connected, PC connected & Stand-alone |
| User Interface Type |
PC, Touch Screen |
| Auto Shut-Off / Power Conserve |
Yes |
Printing Specifications
|
Automatic Label Set Up |
Yes |
| Barcode Symbologies – 2D |
Aztec, Data Matrix, GS1 DataMatrix, MicroPDF417, PDF417, QR code |
| Barcode Symbologies – Linear |
Codabar, Code 128, Code 128A, Code 128B, Code 128C, Code 39, Code 39 Full ASCII, Code 93, Code 93 Full ASCII, EAN-13, EAN-13 Extension 2, EAN-13 Extension 5, EAN-8, EAN-8 Extension 2, EAN-8 Extension 5, GS1-128, HIBC, Industrial 2 of 5, ITF-14, JAN-13, JAN-13 Extension 2, JAN-13 Extension 5, JAN-8, More through Brady WorkStation, More through software, UPC-A, UPC-E |
| Calibration Required? |
Automated with i75-Series Consumables |
| Colour Printing Capability |
Single Color |
| Font Sizes |
4 – 250 pt |
| Font Styles |
Arial, Brady Bold Cond, Noto Sans, Noto Sans Thai, See Brady Workstation, Times New Roman, TrueType fonts storable to printer |
| Maximum Labels per Day |
7000 |
| Maximum Print Speed (mm/sec) |
152.4 |
| Print resolution (dpi) |
600 |
| Print Technology |
Direct Thermal, Thermal Transfer |
| On Screen Indicators |
Bluetooth Status, Data Reception, Digital Clock, Error Messaging, Ethernet Status, i75 Smart material / Manual Material, Label dimensions, Print Job Preview, Ready State, Ribbon and label part number recognition, Supply Remaining, USB Connection, User-defined Printer Name, WiFi |
| Compatibility |
Compatible Media |
2FR-, 2HT-, 2HX-, 2LSZH-, 3FR-, 3HT-, 3PS-, APL-, DR-, DT-, FR-, HCM-, HSNX-, HT-, HX-, i75-, LSZH-, PS-, THT-, THTC-, THTCLP-, THTCLT, THTEL-, THTEP-, THTFP-, THTFT-, THTHD-, THTPNP-, THTRDS-, THTRO-, THTTL-, XTHT- |
| Label Material Types |
Diesel-resistant Heat-shrink Polyolefin Sleeve, Direct Thermal Paper, FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Metallic, Non-metal Polyester, Metallized Polyester, Nylon Cloth, Paper, Polyester, Polyethylene Foam Laminate Polyester, Polyethylene Tag, Polyimide, Polypropylene, Polyvinylfluoride, Repositionable Paper, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallized Polyester, Tamper-evident Polyester, Tamper-resistant Metallized Vinyl, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth |
| Materials Supported |
Bulk, Continuous, Custom, Die-cut |
| Custom Labels Available |
Yes |
| Maximum Label/Tape Width (mm) |
107.9 |
| Maximum Print Width (mm) |
105.66 |
| Maximum Printed Label Length (m) |
18.29 |
| Software Compatibility |
Brady Workstation, Express Labels Mobile App, Windows based driver for 3rd party software use |
| Languages Available |
Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional and Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (Canada), German, Hungarian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Spanish (universal), Thai, Turkish, Vietnamese |
